| DATE GENERALE |
|
| Tip invertor |
OFF-Grid, Hybrid cu functie de paralel |
| Brand |
Breckner Germany |
| Seria |
SY-6.2K-48V |
| Dimensiuni |
450 x 300 x 130 mm |
| Greutate |
9.6 Kg |
| Clasa protectie |
IP21 |
| INTRARE |
|
| Putere nominala |
6200 VA/500W |
| Unda |
Sinusoidala pura |
| Frecventa nominala de intrare |
50/60 Hz ( detectare automata) |
| Intrare DC |
48 VDC / 135A |
| IESIRE |
|
| Iesire AC |
230 VAC, 50/60Hz, 27A, monofazat (1Φ) |
| Eficienta PEAK |
94 % |
| INCARCARE BATERII |
|
| Tensiune baterii |
48 VDC |
| Intare AC |
230VAC, 50/60Hz, 40A, monofazat (1Φ) |
| Iesire DC |
54 VDC |
| Curent maxim de incarcare(AC) |
80A (implicit setat la 30A) |
| Curent maxim combinat(PV+AC) |
120A |
| Iesire AC |
230VAC, 50/60Hz, 27A, monofazat (1Φ) |
| Tip baterii |
Gel, Plumb-acid, AGM |
| PANOURI PV |
|
| Putere maxima de la panouri |
6500 W |
| Tensiune minima de la panouri |
60 VDC |
Tensiunie maxima de la panouri VOC
|
500 VDC |
| Curent panouri maxim |
27A |
| Curent maxim de incarcare MPPT |
120 A |
